Chemical composition

Physical properties

Monel 401 Material Propertie

The chemical composition of the alloy is mainly composed of 30% Cu and 65% Ni with a small amount of Fe (1%-2%). Due to the difference in chemical composition, it can have a variety of alloy grades, but there is no significant difference in corrosion resistance between them. Monel401 alloy is more resistant to corrosion by reducing media than pure nickel, and more resistant to corrosion by oxidative media than pure copper. Monel401 is a deformable nickel-copper-based nickel-based alloy with good seawater corrosion resistance and chemical corrosion resistance, as well as chloride stress corrosion cracking resistance. This alloy is one of the few alloys that can be used in fluoride. It has good resistance to oxide stress fission corrosion in hydrofluoric acid and fluorine gas media, such as seawater and saltwater environments.

Advantage

1. Exceptional corrosion resistance in diverse media.

2. Good resistance to chloride stress corrosion cracking.

3. Versatile suitability for various environments and applications.

4. Deformability for easy shaping and fabrication.

5. Strong resistance to chemical corrosion.

6. Reliable performance in chloride-rich environments.

Application areas of Monel 401 material

Monel 401 is mainly used in chemical and petrochemical and marine development fields. It can be used to manufacture various heat exchange equipment, boiler feed water heaters, petroleum and chemical pipelines, vessels, towers, tanks, valves, pumps, reactors, shafts, etc. Marine heat exchangers, desalination equipment, salt production equipment, marine and chemical processing equipment, propeller shafts and pumps, gasoline and water tanks, etc.
