Chemical composition

Physical properties

Inconel 625 Features

1. Excellent corrosion resistance to various corrosive media in oxidizing and reducing environments

2. Excellent resistance to pitting corrosion and crevice corrosion, and will not produce chloride ion stress corrosion cracking

3. Excellent corrosion resistance to inorganic acids, such as nitric acid, phosphoric acid, sulfuric acid, hydrochloric acid and mixed acids of sulfuric acid and hydrochloric acid, etc.

4. Excellent resistance to corrosion of various inorganic acid mixed solutions

5. When the temperature reaches 40℃, it can show good corrosion resistance in various concentrations of hydrochloric acid solution

6. Good workability and weldability, no post-weld cracking sensitivity

7. Manufacture certification of pressure vessels with wall temperature of -196～450℃

8. Certified by the American Society of Corrosion Engineers NACE standard (MR-01-75) to meet the highest standard level VII for use in sour gas environments.

Advantages

1. High-Temperature Strength: Maintains exceptional strength at elevated temperatures.

2. Oxidation Resistance: Resists oxidation and carburization effectively.

3. Creep Resistance: Shows excellent resistance to creep deformation.

4. Corrosion Resistance: Exhibits good resistance to corrosion in aggressive environments.

5. Fabricability: Easily machined, welded, and fabricated into complex shapes.

6. Weldability: Offers good weldability without compromising mechanical properties.

7. Compatibility: Compatible with various industrial applications.

8. Longevity: Ensures extended service life and reliability.

Inconel625 application areas

The softened and annealed low carbon alloy 625 is widely used in the chemical process industry, and its better corrosion resistance and high strength enable it to be used as a thinner structural component. Alloy 625 can be used in applications exposed to seawater and subject to high mechanical stress. Typical application areas:

1. Components of organic chemical processes containing chlorides, especially where acid chloride catalysts are used

2. Digesters and bleaching tanks for the pulp and paper industry

3. Absorption tower, reheater, flue gas inlet baffle, fan (humid), agitator, deflector and flue in flue gas desulfurization system

4. For the manufacture of equipment and components for use in sour gas environments

5. Acetic acid and acetic anhydride reaction generator

6. Sulfuric acid condenser
